Specification Data Sheet

Heavy duty wall mounted electronic faucet, activated by an infrared sensor. Powered by an internal 9V battery for theft prevention. Includes a low battery level indicator. Latching solenoid valve located inside the product for added vandal protection. Filters included. For cold or premixed water (single inlet). Customizable settings by optional remote control: sensor range, security time, delay In, delay out and on-off. 24 hour mandatory hygiene flush option available upon request.

Operation

Touch-free electronic faucet operated by an infrared sensor. The faucet automatically activates when users place their hands within sensor range and deactivates when removed from the sensor range.


Typical applications:

  • Transportation hubs
  • Offices
  • Hospitals
  • Food outlets
  • Sport facilities
  • Detention centres
  • Homes

Special uniquely dedicated ranges:

  • Detention centres
  • Medical sectors
  • Residential market
  • Specific religious audiences

Features

  • Suitable for solid wall installations
  • Built-in core elements
  • Optional AISI316 stainless steel body
  • Easy to install and maintain
  • Ideal combination with TZ-FLOWSOAP1 Tubular 2030 Electronic Soap Dispenser Wall Mount
  • AS 1428.1 accessible compliant when installed following AS 1428.1 guidelines

Technical Information

  • WELS: 6 Star Rating (6.0L/min)
  • Nominal Flow Rate (LPM): 5.15
  • WaterMark: AS/NZS 3718 Lic.022348
  • Installation: wall mounted
  • Power Supply: 9V battery
  • Operating Pressure: 0.5-8.0 bar / 7.0-116.0 PSI
  • Water Supply: Cold or premixed water
  • Water Flow: 1.58 GPM - SSR PCA stream
  • Water Saving Options: 4 LPM / 1 GPM, 3 LPM / 0.8 GPM, 1.89 LPM / 0.5 GPM, 1.3 LPM 0.35 GPM - PCA spray
  • Water Temperature: 70°C Maximum
  • Security Time: Auto shutoff after 90 seconds. Customizable by remote control

Optional Extras

  • TZ-FLOWSOAP1 Flowmatic® Tubular 2030 Electronic Soap Dispenser Wall Mount Pair with TZ-FLOW225866
  • TZ-FLOW07100005 Flowmatic® Wall Mtd Sensor Remote Control Only to Suit TZ-FLOW225866 Tap

Environmental Sustainability

We are ISO 14001 certified and take sustainability seriously. Our products are environmentally responsible designed to be healthier for users, save water and/or energy, and minimise carbon footprint. Our target is to reduce our carbon footprint by 25%, and the use of non-recyclable/non-compostable materials across the company (e.g. plastics) by 50%.

Warranty

Galvin Engineering products are covered under our Manufacturer's Warranty. Galvin Engineering products must be installed in accordance with the installation instructions and in accordance with AS 3500 and NCC Volume Three, relevant Australian Standards and local authorities applicable to product being installed. Water and electrical supply conditions must also comply to the applicable national and/or state standards, failing to comply with these provisions may void the product warranty and affect performance of the product.

Please visit www.galvinengineering.com.au to view the full warranty, our Installation Compliance and Maintenance & Cleaning information as well as any other additional information.

While all reasonable care has been taken in compiling the information in this document, the designs, dimensions and products shown are indicative only and should not be relied upon without our prior approval. Due to our policy of continuous development, we reserve the right to alter any details of specifications or products without notice. All information, drawings, technical specifications and product designs remain the property of Galvin Engineering Pty Ltd.
