Specification Data Sheet

Features

  • Grade 304 stainless steel grab rail with satin finish
  • Hygienic health safe flange covers
  • ABS slide cradle fastened and tensioned to the grab rail for handset support and movement
  • Strong and stylish ABS hand piece
  • PVC reinforced smooth and flexible spiral hose
  • Chrome on brass wall outlet elbow which features
  • Interchangeable spigot and separate licensed dual check/non return valves to prevent back siphonage
  • 150mm CliniLever® contra rotating lever handles make showering easier for users with disabilities or limited hand mobility
  • Handles are finished in bright chrome plate finish for added durability and easy cleaning
  • AS 1428.1 accessible compliant

Technical Information

  • WELS: 3 Star Rating (8L/min)
  • Nominal Flow Rate (LPM): 7.92
  • WaterMark: AS/NZS 3718 Lic. WKMA0034
  • Inlet: 1/2" BSP - Female
  • Outlet: Handheld Shower
  • Headwork: Jumper Valve
  • Working Pressure Range (kPa): Min 150 - Max 500
  • Working Temperature Range (°C): Min 5 - Max 55
  • Finish: Chrome

Alternative Product Options

  • TCS9C80C CliniLever® CP-BS Hospital Shower Set 80 C/D with Medi Hand Shower & 900mm SS Grab Rail
  • TCS9J80C CliniLever® CP-BS Hospital Shower Set 80 J/V with Medi Hand Shower & 900mm SS Grab Rail
  • TCS9C150C CliniLever® CP-BS Hospital Shower Set 150 C/D with Medi Hand Shower & 900mm SS Grab Rail

Environmental Sustainability

We are ISO 14001 certified and take sustainability seriously. Our products are environmentally responsible designed to be healthier for users, save water and/or energy, and minimise carbon footprint. Our target is to reduce our carbon footprint by 25%, and the use of non-recyclable/non-compostable materials across the company (e.g. plastics) by 50%.

Warranty

Galvin Engineering products are covered under our Manufacturer's Warranty. Galvin Engineering products must be installed in accordance with the installation instructions and in accordance with AS 3500 and NCC Volume Three, relevant Australian Standards and local authorities applicable to product being installed. Water and electrical supply conditions must also comply to the applicable national and/or state standards, failing to comply with these provisions may void the product warranty and affect performance of the product.

Please visit www.galvinengineering.com.au to view the full warranty, our Installation Compliance and Maintenance & Cleaning information as well as any other additional information.

While all reasonable care has been taken in compiling the information in this document, the designs, dimensions and products shown are indicative only and should not be relied upon without our prior approval. Due to our policy of continuous development, we reserve the right to alter any details of specifications or products without notice. All information, drawings, technical specifications and product designs remain the property of Galvin Engineering Pty Ltd.
