Specification Data Sheet

The Galvin CliniLever® Lead Safe™ Hospital Basin Set offers easy-to-operate dual levers for precise temperature control during hand washing, as well as, compliance with the latest healthcare guidelines, making it an ideal choice for is ideal for hospitals, aged care facilities, schools, and in-home care.

Features

  • Manufactured using high quality DZR solid brass with less than 0.25% lead content
  • Laminar flow nozzle to reduce the spread of Legionella (supplied standard)
  • Low lying, contra rotating levers allow easy to use handsfree operation
  • Clean smooth design for easy cleaning and to help reduce dirt and bacteria growth
  • Extra high gooseneck outlet for even easier hand washing and to help further reducing the spread of bacteria
  • High quality chrome finish for easy cleaning and hygiene maintenance
  • Australian Made; therefore, spare parts and support are available locally, reducing maintenance and downtime costs
  • AS 1428.1 accessible compliant when installed following AS 1428.1 guidelines

Technical Information

  • WELS: 5 Star Rating (5.5L/min)
  • Nominal Flow Rate: 5.5
  • WaterMark: AS/NZS 3718 Lic. WMKA0034
  • Inlet: ½” CU/BSP
  • Outlet: Laminar Flow
  • Headworks: Jumper Valve
  • Working Pressure Range (kPa): 50 Min - 500 Max
  • Working Temperature Range (°C): 5 Min - 65 Max
  • Construction: Lead Safe™ DZR Brass
  • Finish: Chrome

Spare Parts

Alternative Product Options

  • 102.13.21.03 CliniLever® CP-BS Lead Safe™ Hospital Basin Set with Fixed 150mm Outlet 150 C/D

Superseding Products

  • TCBHFJ150C CliniLever® CP-BS Hospital Basin Set with Fixed 150mm Outlet 150 J/V

Environmental Sustainability

We are ISO 14001 certified and take sustainability seriously. Our products are environmentally responsible designed to be healthier for users, save water and/or energy, and minimise carbon footprint. Our target is to reduce our carbon footprint by 25%, and the use of non-recyclable/non-compostable materials across the company (e.g. plastics) by 50%.

Warranty

Galvin Engineering products are covered under our Manufacturer's Warranty. Galvin Engineering products must be installed in accordance with the installation instructions and in accordance with AS 3500 and NCC Volume Three, relevant Australian Standards and local authorities applicable to product being installed. Water and electrical supply conditions must also comply to the applicable national and/or state standards, failing to comply with these provisions may void the product warranty and affect performance of the product.

Please visit www.galvinengineering.com.au to view the full warranty, our Installation Compliance and Maintenance & Cleaning information as well as any other additional information.

While all reasonable care has been taken in compiling the information in this document, the designs, dimensions and products shown are indicative only and should not be relied upon without our prior approval. Due to our policy of continuous development, we reserve the right to alter any details of specifications or products without notice. All information, drawings, technical specifications and product designs remain the property of Galvin Engineering Pty Ltd.

Our Lead Safe™ product range is compliant with the Lead Free Requirements of the NCC 2022 Vol. Three, Clause A5G4(2) and NSF/ANSI 372.
