Specification Data Sheet

Our Galvin CliniLever® range is specifically designed for hospital and medical preparation areas. The innovative design helps to combat the risk of hospital acquired infections and minimise the risk of bacteria. It provides a time and cost effective solution including easy maintenance thanks to its in-built isolators and inline filters.

Features

  • Patented inline inlet tails with isolator and strainer to protect the control mechanism, extend the life of the unit and minimise downtime when servicing is required
  • Downswept swivel spout
  • Clean smooth design for easy cleaning and to help reduce dirt and bacterial growth
  • Low lying levers allow easy to use handsfree operation
  • Chrome plated finish for added durability
  • Manufactured using Lead Safe™ DZR Brass with less than 0.25% lead content

Technical Information

  • WELS: 5 Star Rating (5.5L/min)
  • Nominal Flow Rate (LPM): 5.1
  • WaterMark: AS/NZS 3718 Lic. WMKA0034
  • Inlet: ½” BSP – Female
  • Outlet: Laminar Flow
  • Headworks: Ceramic
  • Working Pressure Range (kPa): 50 Min - 500 Max
  • Maximum Working Temperature (°C): 5 Min - 65 Max
  • Construction: Brass
  • Finish:  Chrome

Spare Parts

  • 46777 CliniLever® Hospital Surgical Lever Action Indicator Button Only (Blue) Cold
  • 46771 CliniLever® Hospital Surgical Lever Action Indicator Button Only (Red) Hot
  • 46783 CliniLever® Hospital Surgical Lever Action Indicator Button Only (Yellow) Warm

Superseding Products

  • TC57SC1C CliniLever® CP-BS Hospital Wall Mixing Set Type 57 Downswept Swivel 150 C/D

Environmental Sustainability

We are ISO 14001 certified and take sustainability seriously. Our products are environmentally responsible designed to be healthier for users, save water and/or energy, and minimise carbon footprint. Our target is to reduce our carbon footprint by 25%, and the use of non-recyclable/non-compostable materials across the company (e.g. plastics) by 50%.

Warranty

Galvin Engineering products are covered under our Manufacturer's Warranty. Galvin Engineering products must be installed in accordance with the installation instructions and in accordance with AS 3500 and NCC Volume Three, relevant Australian Standards and local authorities applicable to product being installed. Water and electrical supply conditions must also comply to the applicable national and/or state standards, failing to comply with these provisions may void the product warranty and affect performance of the product.

Please visit www.galvinengineering.com.au to view the full warranty, our Installation Compliance and Maintenance & Cleaning information as well as any other additional information.

While all reasonable care has been taken in compiling the information in this document, the designs, dimensions and products shown are indicative only and should not be relied upon without our prior approval. Due to our policy of continuous development, we reserve the right to alter any details of specifications or products without notice. All information, drawings, technical specifications and product designs remain the property of Galvin Engineering Pty Ltd.

Our Lead Safe™ product range is compliant with the Lead Free Requirements of the NCC 2022 Vol. Three, Clause A5G4(2) and NSF/ANSI 372.
