The Galvin CliniMix^® Lead Safe™ CMV2 Wall Mounted Handsfree POU, Proximity Sensor, Glass Face Plate with Temperature Monitoring is suitable for medical or nursing procedures, providing state-of-the-art features to comply with the latest healthcare requirements. Suitable for high and low pressure systems. The proximity sensor will activate when a users hands are in the set detection area.

Features

• Front access for commissioning, servicing and disinfection
• Easy front of wall thermal disinfection with minimal patient interruptions thanks to:
  • no adjustment or resetting of valve required
  • inbuilt thermal disinfection facility for manual flush
  • access via key control port on faceplate
• Multiple time cycle options are adjustable on-site allowing full flexibility to suit user requirements
• NCC 2022 Vol 3, Clause A5G4(2) ‘lead free requirements’ compliant
• Modern high end coloured glass (choice of colours available, 500 order minimum)
• Incorporates CliniMix^® TMV Monitoring System
• Hygienic self draining smooth bore outlet to suit Type A and B basin complying with AusHFG Guidelines
• Consists of inwall box and front of wall finishing kit
• Adjustable handsfree proximity sensor technology minimising the spread of infection
• Enables water to be mixed closer to the point of discharge, reducing risk of Legionella
• Provides stable mixed temperature and rapid shut down in the event of cold/hot water supply failure keeping patients safe

Technical Information

• WaterMark: AS 4032.4 Lic. WMKA21989
• Inlet: 3/4" CU Tube
• Outlet: Flow Straightener
• Headwork: Thermostatic Mixing Valve (TMV)
• Working Pressure Range (kPa): 30 Min - 500 Max
• Permitted Supply Pressure Variation: 10:1
• Mixed Temperature Range (°C): 35 Min - 45 Max
• Factory Set Thermostatic Temperature (°C): 41
• Nominal Flow Rate (LPM): 8
• Power Supply: Mains Powered
• Construction: Lead Safe™ DZR Brass & Glass
• Finish: Chrome & Glass
