This innovative Galvin CliniMix^® Lead Safe™ point of use thermostatic progressive mixer provides state-of-the-art safety features to comply with the latest healthcare requirements. The single lever operates on/off and temperature control for straight forward operation, simplifying hand wash procedures and the long arm is operated handsfree with elbows to avoid hand contact or cross-contamination. Suitable for high and low pressure systems it can be set to deliver a thermostatically controlled water temperature up to 48ºC maximum. Robust and reliable, our CliniMix^® Lead Safe™ thermostatic progressive shower mixer is water conserving and cost-effective.

Features

• Manufactured using Lead Safe™ DZR Brass with less than 0.25% lead content*
• Unique thermal disinfection bypass feature
• Enables water to be mixed closer to the point of discharge. This minimises warm water becoming stagnant which can provide an ideal condition for Legionella bacteria to grow
• Smooth internal and external components to decrease dirt build up
• The long lever sequential control handle is easy to access for users and provides more precise control of temperature
• Water flow always starts from cold for safe usage
• Fast and easy to clean
• All servicing and commissioning can be done without removing the device. Easy to access isolators helps to minimise the time of commissioning and maintenance
• Designed to provide stable mixed temperature and rapid shut down in the event of cold or hot water supply failure

Technical Information

• Nominal Flow Rate (LPM): 8
• WaterMark: AS 4032.4 Lic. WMKA21989
• Inlet: 1/2" BSP - Female
• Outlet: 1/2" BSP - Male
• Headwork: Thermostatic Mixing Valve (TMV)
• Working Pressure Range (kPa): 20 Min - 500 Max
• Working Temperature Range (°C): 5 Min - 85 Max
• Minimum Temp. Differential (Between Supply and Outlet Temp.) (°C): 10
• Adjustable Temperature Range (°C): 35 Min - 48 Max
• Permitted Supply Pressure Variation: 10:1
• Factory Set Thermostatic Temperature (°C): 41
• Maximum Thermostatic Temperature (°C): 48
• Minimum Flow Rate for Stable Outlet Temp. (LPM): 6
• Construction: Lead Safe™ DZR Brass*
• Finish: Chrome
