Australian Made AS/NZS 3718 Watermark approved Galvin Ezy-Drink® Stainless Steel Lead Safe™ Remote Electronic Bottle Filler range is ideal for use in playgrounds, schoolyards, offices and public area drinking troughs. Robust and reliable, our Ezy-Drink® 316 Stainless Steel Lead Safe™ Remote Electronic Bottle Filler range is water conserving and cost-effective. Stainless steel material is completely free of lead as no lead is used in its production.Stainless steel material is completely free of lead as no lead is used in its production.

Features

  • 316 stainless steel construction
  • Hygiene rinse can be set to activate at regular 12, 24 or 48 hour intervals to remove any stagnant water. This will reduce the amount of metals that may leach into the water from the plumbing system, and assist in minimising the growth of bacteria such as Legionella
  • Vandal resistant design
  • Inbuilt adjustment for consistency of water flow
  • Easy to use self-closing mechanism
  • High quality chrome finish for easy cleaning and hygiene maintenance
  • Australian Made; therefore, spare parts and support are available locally, reducing maintenance downtime costs

Technical Information

  • WELS: 6 Star Rating (2.0L/min)
  • Nominal Flow Rate (LPM): 1.70
  • WaterMark: AS/NZS 3718 Lic. WMKA0034
  • Inlet: 1/2" BSP - Female
  • Outlet: Gooseneck
  • Headwork: Solenoid
  • Working Pressure Range (kPa): 50 Min - 500 Max
  • Working Temperature Range (°C): 5 Min - 60 Max
  • Construction: 316 Stainless Steel
  • Finish: Stainless Steel

Spare Parts

  • 170.94.40.00 Ezy-Drink® CP-BS Lead Safe™ Bottle Filler Replacement Gooseneck Spout

Alternative Product Options

  • 170.13.33.00 Ezy-Drink® CP-BS Lead Safe™ Hob Mtd Bottle Filler Tap with Reduced Flange - MI (RH)
  • 170.13.36.00 Ezy-Drink® CP-BS Lead Safe™ Hob Mtd Bottle Filler - MI (RH)
  • 85326X Ezy-Drink® SS316 Lead Safe™ Remote Bottle Filler Outlet

Environmental Sustainability

We are ISO 14001 certified and take sustainability seriously. Our products are environmentally responsible designed to be healthier for users, save water and/or energy, and minimise carbon footprint. Our target is to reduce our carbon footprint by 25%, and the use of non-recyclable/non-compostable materials across the company (e.g. plastics) by 50%.

Warranty

Galvin Engineering products are covered under our Manufacturer's Warranty. Galvin Engineering products must be installed in accordance with the installation instructions and in accordance with AS 3500 and NCC Volume Three, relevant Australian Standards and local authorities applicable to product being installed. Water and electrical supply conditions must also comply to the applicable national and/or state standards, failing to comply with these provisions may void the product warranty and affect performance of the product.

Please visit www.galvinengineering.com.au to view the full warranty, our Installation Compliance and Maintenance & Cleaning information as well as any other additional information.

While all reasonable care has been taken in compiling the information in this document, the designs, dimensions and products shown are indicative only and should not be relied upon without our prior approval. Due to our policy of continuous development, we reserve the right to alter any details of specifications or products without notice. All information, drawings, technical specifications and product designs remain the property of Galvin Engineering Pty Ltd.

Our Lead Safe™ product range is compliant with the Lead Free Requirements of the NCC 2022 Vol. Three, Clause A5G4(2) and NSF/ANSI 372.
