Specification Data Sheet

Avoiding hand contact with tapware helps reduce the risk of cross-contamination, which is particularly important in food preparation and processing areas. Galvin Ezy-Lever Lead Safe™ Knee Operated Valve's soft spring is perfect for handsfree operation and is easily mounted. It has a self-closing function which reduces water and energy wastage.

Features

  • Commercial grade quality and fully backed up by our industrial warranty
  • Timeflow shut off for major water and electricity savings
  • Handsfree operation to support infection control and save on cleaning time
  • Robust lever for heavy usage
  • High quality chrome finish for easy cleaning and hygiene maintenance

*Please ensure this valve is installed in compliance with WaterMark outlet.

Technical Information

  • Inlet:  ½" BSP - Male
  • Outlet:  ½” BSP - Male
  • Headwork:  Time Flow Cartridge
  • Working Pressure Range (kPa): 100 Min - 500 Max
  • Working Temperature Range (°C): 5 Min - 65 Max
  • Construction: Lead Safe™ DZR Brass
  • Finish: Chrome

Spare Parts

  • 173.92.44.00 Ezy-Lever CP-BS Lead Safe™ Timeflow Cartridge for Knee Operated Valve (suit 173.61.44.00)

Superseding Products

  • TP08045 CP-BS Knee Operated Timeflow Valve with Regulator

Environmental Sustainability

We are ISO 14001 certified and take sustainability seriously. Our products are environmentally responsible designed to be healthier for users, save water and/or energy, and minimise carbon footprint. Our target is to reduce our carbon footprint by 25%, and the use of non-recyclable/non-compostable materials across the company (e.g. plastics) by 50%.

Warranty

Galvin Engineering products are covered under our Manufacturer's Warranty. Galvin Engineering products must be installed in accordance with the installation instructions and in accordance with AS 3500 and NCC Volume Three, relevant Australian Standards and local authorities applicable to product being installed. Water and electrical supply conditions must also comply to the applicable national and/or state standards, failing to comply with these provisions may void the product warranty and affect performance of the product.

Please visit www.galvinengineering.com.au to view the full warranty, our Installation Compliance and Maintenance & Cleaning information as well as any other additional information.

While all reasonable care has been taken in compiling the information in this document, the designs, dimensions and products shown are indicative only and should not be relied upon without our prior approval. Due to our policy of continuous development, we reserve the right to alter any details of specifications or products without notice. All information, drawings, technical specifications and product designs remain the property of Galvin Engineering Pty Ltd.

Our Lead Safe™ product range is compliant with the Lead Free Requirements of the NCC 2022 Vol. Three, Clause A5G4(2) and NSF/ANSI 372.
