Specification Data Sheet

The Brass Lead Safe™ Lever Action SBA range is designed for use with Ezy-Wash® Pre-Rinse units. These components are available with ceramic cartridge and jumper valve headworks.

Technical Information

  • WaterMark AS/NZS 3718 Lic. WMKA0034
  • Inlet: G 5/8” BSP – Male
  • Headworks: Ceramic Disc
  • Working Pressure Range (kPa): Min 50 - Max 500
  • Working Temperature Range (°C): Min 5 - Max 65
  • Construction: Lead Safe™ DZR Brass*
  • Finish: Brass

Superseding Products

  • 46672 BS Lever Action Pre-Rinse SBA C/D - Cold

This product is compatible with

  • 102.20.21.00 CliniLever® CP-BS Lead Safe™ Hospital Wall Mixing Set Type 51 Fixed 150 C/D
  • 102.11.21.00 CliniLever® CP-BS Lead Safe™ Hospital Hob Mixing Set Type 50 Swivel 150 C/D
  • 181.20.10.00 Ezy-Wash CP-BS Lead Safe™ Lever Action Twin Mixer Sink Set C/D with 200 Upswept Spout & 80 Lever
  • 181.20.11.00 Ezy-Wash CP-BS Lead Safe™ Lever Action Twin Mixer Sink Set C/D with 300 Upswept Spout & 80 Lever
  • 102.21.21.00 CliniLever® CP-BS Lead Safe™ Hospital Wall Mixing Set Type 51 Swivel 150 C/D
  • 102.23.21.00 CliniLever® CP-BS Lead Safe™ Hospital Wall Mixing Set Type 56 Fixed 150 C/D
  • 102.24.21.00 CliniLever® CP-BS Lead Safe™ Hospital Wall Mixing Set Type 57 Downswept Swivel 150 C/D
  • 181.04.10.01 Ezy-Wash® CP-BS Lead Safe™ Hob Mtd Pot & Kettle Filler Unit Type 70H with Folding Outlet & Stop
  • 181.19.30.01 Ezy-Wash® CP-BS Wall Mtd Pot & Kettle Filler Unit Type 70 with Folding Outlet & Stop
  • 102.10.21.00 CliniLever® CP-BS Lead Safe™ Hospital Hob Mixing Set Type 50 Fixed 150 C/D
  • 102.16.21.00 CliniLever® CP-BS Lead Safe™ Hospital Pillar Tap 150 C/D
  • 102.16.22.00 CliniLever® CP-BS Lead Safe™ Hospital Pillar Tap 80 C/D
  • 102.22.21.00 CliniLever® CP-BS Lead Safe™ Hospital Wall Bib Tap Type 54 Fixed 150 C/D
  • 102.19.21.01 CliniLever® CP-BS Lead Safe™ Basin/Sink Top Assembly 150 C/D Cold
  • 102.19.22.01 CliniLever® CP-BS Lead Safe™ Basin/Sink Top Assembly 80 C/D Cold
  • 102.60.21.01 CliniLever® CP-BS Lead Safe™ Hospital Wall Top Assembly 150 C/D Cold
  • 102.60.22.01 CliniLever® CP-BS Lead Safe™ Hospital Wall Top Assembly 80 C/D Cold
  • 102.90.21.01 CliniLever® BS Lead Safe™ Hospital Surgical SBA Cold C/D
  • 181.94.52.01 Ezy-Wash® BS Lead Safe™ Lever Action Pre-Rinse TF70/84 Hob SBA C/D - Cold

Environmental Sustainability

We are ISO 14001 certified and take sustainability seriously. Our products are environmentally responsible designed to be healthier for users, save water and/or energy, and minimise carbon footprint. Our target is to reduce our carbon footprint by 25%, and the use of non-recyclable/non-compostable materials across the company (e.g. plastics) by 50%.

Warranty

Galvin Engineering products are covered under our Manufacturer's Warranty. Galvin Engineering products must be installed in accordance with the installation instructions and in accordance with AS 3500 and NCC Volume Three, relevant Australian Standards and local authorities applicable to product being installed. Water and electrical supply conditions must also comply to the applicable national and/or state standards, failing to comply with these provisions may void the product warranty and affect performance of the product.

Please visit www.galvinengineering.com.au to view the full warranty, our Installation Compliance and Maintenance & Cleaning information as well as any other additional information.

While all reasonable care has been taken in compiling the information in this document, the designs, dimensions and products shown are indicative only and should not be relied upon without our prior approval. Due to our policy of continuous development, we reserve the right to alter any details of specifications or products without notice. All information, drawings, technical specifications and product designs remain the property of Galvin Engineering Pty Ltd.

Our Lead Safe™ product range is compliant with the Lead Free Requirements of the NCC 2022 Vol. Three, Clause A5G4(2) and NSF/ANSI 372.
