Specification Data Sheet

The GalvinAssist® healthcare range provides safe and reliable showering for both able-bodied people and people with disabilities. When considering the shower cubicle options in care facilities or bathrooms provisions for assistance must be considered where someone is incapable of performing the cleaning task unaided.

Features

  • Grade 304 stainless steel grab rail with satin finish
  • Hygienic health safe flange covers
  • ABS slide cradle fastened and tensioned to the grab rail for handset support and movement
  • Strong and stylish ABS hand piece
  • PVC reinforced smooth and flexible spiral hose
  • Chrome on brass wall outlet elbow which features 9 L/min flow
  • Interchangeable spigot and separate licensed dual check/non-return valves to prevent back-siphonage
  • AS 1428.1 accessible compliant

Technical Information

  • WELS: 3 Star Rating (8L/min)
  • Nominal Flow Rate (LPM): 7.92
  • WaterMark: AS/NZS 3662 Lic. WMK26191
  • Inlet: G 1/2" Female
  • Outlet: ABS Plastic Handheld Shower
  • Headwork: N/A
  • Working Pressure Range (kPa): 150 Min - 500 Max
  • Working Temperature Range (°C): 5 Min - 55 Max
  • Construction: Stainless Steel / Brass / PVC / ABS Plastic
  • Finish: Polished / Chrome

Alternative Product Options

  • 41935 GalvinAssist® Hand Shower Kit with 1000 x 32mm SS Hygienic Grab Rail & Pull Rod
  • 41996 GalvinAssist® Hand Shower Kit with 600 x 32mm SS Hygienic Grab Rail
  • 41999 GalvinAssist® Hand Shower Kit with 900 x 32mm SS Hygienic Grab Rail
  • 41999CP GalvinAssist® CP Hand Shower Kit with 900 x 32mm SS Hygienic Grab Rail

Environmental Sustainability

We are ISO 14001 certified and take sustainability seriously. Our products are environmentally responsible designed to be healthier for users, save water and/or energy, and minimise carbon footprint. Our target is to reduce our carbon footprint by 25%, and the use of non-recyclable/non-compostable materials across the company (e.g. plastics) by 50%.

Warranty

Galvin Engineering products are covered under our Manufacturer's Warranty. Galvin Engineering products must be installed in accordance with the installation instructions and in accordance with AS 3500 and NCC Volume Three, relevant Australian Standards and local authorities applicable to product being installed. Water and electrical supply conditions must also comply to the applicable national and/or state standards, failing to comply with these provisions may void the product warranty and affect performance of the product.

Please visit www.galvinengineering.com.au to view the full warranty, our Installation Compliance and Maintenance & Cleaning information as well as any other additional information.

While all reasonable care has been taken in compiling the information in this document, the designs, dimensions and products shown are indicative only and should not be relied upon without our prior approval. Due to our policy of continuous development, we reserve the right to alter any details of specifications or products without notice. All information, drawings, technical specifications and product designs remain the property of Galvin Engineering Pty Ltd.
