Specification Data Sheet

The GalvinLab® CP-BS Lead Safe™ #16XT Tube Nozzle with Integral Dual Check is a suitable spare part for GalvinLab®  laboratory tapware.

Features

  • High quality chrome finish for easy cleaning and hygiene maintenance
  • Australian Made; therefore, spare parts and support are available locally, reducing costs of down time on maintenance

Technical Information

  • WaterMark: AS/NZS 3718 Lic. WMKA0034
  • Inlet: M22 x 1p
  • Working Pressure Range (kPa): 50 Min - 500 Max
  • Working Temperature Range (°C): 5 Min - 65 Max
  • Construction: Lead Safe™ DZR Brass
  • Finish: Brass

Superseding Products

  • 47122 BS Capstan 1/2 Turn Pillar / Basin SBA

This product is compatible with

  • 167.16.31.00 GalvinLab® CP-BS Lead Safe™ Lab Set 1-Way Type 16 DPW Fixed J/V #16XT Tube Nozzle
  • 167.16.21.00 GalvinLab® CP-BS Lead Safe™ Lab Set 1-Way Type 16 Fixed J/V #16XT Tube Nozzle
  • 167.16.21.01 GalvinLab® CP-BS Lead Safe™ Lab Set 1-Way Type 16 Fixed J/V Lever Handle Tube Nozzle
  • 167.16.27.01 GalvinLab® CP-BS Lead Safe™ Lab Set 1-Way Type 16 Fixed J/V Lever Handle Tube Nozzle - LH
  • 167.16.27.00 GalvinLab® CP-BS Lead Safe™ Lab Set 1-Way Type 16 Fixed J/V Tube Nozzle - LH
  • 167.16.11.00 GalvinLab® CP-BS Lead Safe™ Lab Set 1-Way Type 16 Swivel J/V #16XT Tube Nozzle
  • 167.14.20.00 GalvinLab® CP-BS Lead Safe™ Lab Set H&C Mixing Unit Type 14 Fixed J/V Aerator #1 &#16XT Tube Nozzles
  • 167.14.11.00 GalvinLab® CP-BS Lead Safe™ Lab Set H&C Mixing Unit Type 14 Swivel J/V #16XT Tube Nozzles
  • 167.13.11.00 GalvinLab® CP-BS Lead Safe™ Lab Set H&C Mixing Unit Type 13 Swivel J/V #16XT Tube Nozzle
  • 167.19.11.00 GalvinLab® CP-BS Lead Safe™ Lab Set H&C Mixing Unit Type 19 Swivel J/V #16XT Tube Nozzle
  • 167.17.21.00 GalvinLab® CP-BS Lead Safe™ Lab Set 1-Way R/A Valve Type 17 Fixed J/V #16XT Tube Nozzle
  • 167.05.21.00 GalvinLab® CP-BS Lead Safe™ Lab Set 1-Way Type 5 Fixed J/V #16XT Tube Nozzle
  • 167.08.30.00 GalvinLab® CP-BS Lead Safe™ Lab Set 2-Way Type 8 DPW Fixed J/V #8 Aerator #16XT Tube Nozzle
  • 167.08.11.00 GalvinLab® CP-BS Lead Safe™ Lab Set 2-Way Type 8 Swivel J/V #16XT Tube Nozzle
  • 167.07.20.00 GalvinLab® CP-BS Lead Safe™ Lab Set 3-Way Type 7 Fixed J/V #1 Aerator & #16XT Tube Nozzle
  • 167.07.11.00 GalvinLab® CP-BS Lead Safe™ Lab Set 3-Way Type 7 Swivel J/V #16XT Tube Nozzle
  • 167.06.21.00 GalvinLab® CP-BS Lead Safe™ Lab Set 2-Way Type 6 Fixed J/V #16XT Tube Nozzle

Environmental Sustainability

We are ISO 14001 certified and take sustainability seriously. Our products are environmentally responsible designed to be healthier for users, save water and/or energy, and minimise carbon footprint. Our target is to reduce our carbon footprint by 25%, and the use of non-recyclable/non-compostable materials across the company (e.g. plastics) by 50%.

Warranty

Galvin Engineering products are covered under our Manufacturer's Warranty. Galvin Engineering products must be installed in accordance with the installation instructions and in accordance with AS 3500 and NCC Volume Three, relevant Australian Standards and local authorities applicable to product being installed. Water and electrical supply conditions must also comply to the applicable national and/or state standards, failing to comply with these provisions may void the product warranty and affect performance of the product.

Please visit www.galvinengineering.com.au to view the full warranty, our Installation Compliance and Maintenance & Cleaning information as well as any other additional information.

While all reasonable care has been taken in compiling the information in this document, the designs, dimensions and products shown are indicative only and should not be relied upon without our prior approval. Due to our policy of continuous development, we reserve the right to alter any details of specifications or products without notice. All information, drawings, technical specifications and product designs remain the property of Galvin Engineering Pty Ltd.

Our Lead Safe™ product range is compliant with the Lead Free Requirements of the NCC 2022 Vol. Three, Clause A5G4(2) and NSF/ANSI 372.
