Specification Data Sheet

The HeelGrate® range of floor drains has been designed to address concerns about possible accidental injury to pedestrians, caused by high heel shoes penetrating grates. The design of the grates also minimises potential problems where tips of crutches, wheelchair wheels or small children’s toes could become lodged in the grates.

Features

  • Stainless steel lock down allen key screws
  • Machined surface
  • 5mm gaps between bars to prevent possible accidental injury to pedestrians caused by high-heel shoes penetrating grates
  • Suitable for concourse paving, tile and concrete applications
  • Slip-In PVC/HDPE/CU with the added feature of height adjustment
  • WaterMark: WMTS 040 Lic. WMK02448

Optional Extras

  • 303685 Stainless Steel Sediment Bucket 150 Nom
  • 303644 Stainless Steel Strainer Basket 150 Nom

Spare Parts

  • 302600X HeelGrate® SS316 Floor Drain Grate Square 200x150 BSP
  • 302173 ABS Floor Drain Adaptor 150BSP FI x 150PVC Slip-in

Environmental Sustainability

We are ISO 14001 certified and take sustainability seriously. Our products are environmentally responsible designed to be healthier for users, save water and/or energy, and minimise carbon footprint. Our target is to reduce our carbon footprint by 25%, and the use of non-recyclable/non-compostable materials across the company (e.g. plastics) by 50%.

Warranty

Galvin Engineering products are covered under our Manufacturer's Warranty. Galvin Engineering products must be installed in accordance with the installation instructions and in accordance with AS 3500 and NCC Volume Three, relevant Australian Standards and local authorities applicable to product being installed. Water and electrical supply conditions must also comply to the applicable national and/or state standards, failing to comply with these provisions may void the product warranty and affect performance of the product.

Please visit www.galvinengineering.com.au to view the full warranty, our Installation Compliance and Maintenance & Cleaning information as well as any other additional information.

While all reasonable care has been taken in compiling the information in this document, the designs, dimensions and products shown are indicative only and should not be relied upon without our prior approval. Due to our policy of continuous development, we reserve the right to alter any details of specifications or products without notice. All information, drawings, technical specifications and product designs remain the property of Galvin Engineering Pty Ltd.
