Our range of Galvin Vandal Resistant Tapware is manufactured to comply to all relevant standards. The range is designed primarily for use in busy public areas where a long lasting tap is essential.
Kit Inclusions
Note: Items are packed separately.
Features
- Aerator and 15mm BSP Female Inlet
- High quality chrome finish for easy cleaning and hygiene maintenance
- Australian Made; therefore, spare parts and support are available locally, reducing maintenance and downtime costs
- Dual WELS Rating (6 and 5 Star Rating)
Note: This product is registered via WELS with two performance ratings to ensure its suitability across a diverse array of applications. Installed in the product is the 6 Star Rating flow regulator for optimal performance. For added flexibility, the additional flow regulator is also provided within the carton. You can easily switch between regulators as needed, all while preserving the product's WELS certification. Refer to the installation instructions for a comprehensive guide on changing the flow regulator.
Technical Information
- WELS: 6 Star (3.5L/min) or 5 Star Rating (5L/min)
- Nominal Flow Rate (LPM): 3.41 or 4.9
- WaterMark: AS/NZS 3718 Lic. WMKA0034
- Inlet: ½” BSP – Female
- Outlet: Laminar Flow Aerator
- Headwork: N/A
- Working Pressure Range (kPa): Min 50 - Max 500
- Working Temperature Range (°C): Min 5 - Max 80
- Construction: Lead Safe™ DZR Brass
- Finish: Chrome
Features
- Vandal resistant handle with locking ring to secure handle to the spindle which may only be removed using the key provided
- Standard with jumper valve
- Half turn ceramic disc available on request
- Chrome finish for easy cleaning and hygiene maintenance
Technical Information
- WaterMark: AS/NZS 3718 Lic. WMKA0034
- Inlet: 5/8" BSP - Male
- Headwork: Jumper Valve
- Working Pressure Range (kPa): 50 Min - 500 Max
- Working Temperature Range (°C): 5 Min - 60 Max
- Construction: DZR Lead Safe™ Brass*
- Finish: Chrome
Features
- Vandal resistant handle with locking ring to secure handle to the spindle which may only be removed using the key provided
- Standard with jumper valve
- Half turn ceramic disc available on request
- Chrome finish for easy cleaning and hygiene maintenance
Technical Information
- WaterMark: AS/NZS 3718 Lic. WMKA0034
- Inlet: 5/8" BSP - Male
- Headwork: Jumper Valve
- Working Pressure Range (kPa): 50 Min - 500 Max
- Working Temperature Range (°C): 5 Min - 60 Max
- Construction: DZR Lead Safe™ Brass*
- Finish: Chrome
Our Lead Safe™ product range is compliant with the Lead Free Requirements of the NCC 2022 Vol. Three, Clause A5G4(2) and NSF/ANSI 372.
Superseding Products
- 49944 Vandal Resistant CP-BS J/V Wall Sink Set (NSW) with 165 Fixed Spout & Aerator
Spare Parts
- 167.93.11.01 GalvinLab® CP-BS Lead Safe™ Wall Trough Outlet 165 with Vandal Resistant Aerator
- 174.01.02.01 Vandal Resistant CP Lead Safe™ J/V Wall Top Assembly Cold
- 174.01.02.02 Vandal Resistant CP Lead Safe™ J/V Wall Top Assembly Hot
